| Switch type | Managed |
| Switch layer | L2 |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Networking standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x |
| 10G support | No |
| Port mirroring | Yes |
| Link aggregation | Yes |
| Broadcast storm control | Yes |
| Rate limiting | Yes |
| VLAN support | Yes |
| Number of VLANs | 32 |
| Switching capacity | 16 Gbit/s |
| MAC address table | 4000 entries |
| Store-and-forward | Yes |
| Jumbo frames support | Yes |
| Jumbo frames | 15000 |
| Packet forwarding rate (1 Gbps) | 11900000 pps |
| Packet buffer memory | 1.5 MB |
| IGMP snooping | Yes |
| Loop protection | Yes |
| Rack mounting | No |
| Product colour | Black |
| LED indicators | Activity, Link, PoE, Power, Speed, Status |
| Power supply included | Yes |
| AC input voltage | 220 V |
| AC input frequency | 50 Hz |
| Input current | 1.25 A |
| Power consumption (max) | 65.2 W |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) ports quantity | 4 |
| Power over Ethernet plus (PoE+) ports quantity | 4 |
| Total Power over Ethernet (PoE) budget | 55 W, 64 W |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 95% |
| Width | 158 mm |
| Depth | 101 mm |
| Height | 25 mm |
| Cables included | AC |
| User guide | Yes |
| Package type | Box |
| Certification | FCC, CE, RoHS |
| Harmonized System (HS) code | 85176990 |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
| Gigabit Ethernet (copper) ports quantity | 8 |
| Cable types supported | Cat3, Cat4, Cat5, Cat5e, Cat6 |
| Auto MDI/MDI-X | Yes |
| Auto-negotiation | Yes |
| Virtual LAN features | Port-based VLAN |
| Forwarding rate | 11.9 Mpps |
| Power source | DC |
| Input voltage | 48 V |
| Power over Ethernet (PoE) power per port | 15.4 W |
| Heat dissipation | 256.19 BTU/h |
| Package width | 131 mm |
| Package depth | 196 mm |
| Package height | 121 mm |
| Package weight | 860 g |
