| Video input channels | 4 channels |
| Number of simultaneously playbacked channels | 4 channels |
| Video recording modes | 720p, 1080p |
| Maximum resolution | 3840 x 2160 pixels |
| Supported resolutions | HDMI^ 3840x2160/30Hz,1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1024x768/60Hz, 1280x720/60Hz VGA: 1920x1080/60Hz,1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1024x768/60Hz, 1280x720/60Hz |
| On Screen Display (OSD) | Yes |
| Video formats supported | H.264, H.264+, H.265, H.265+ |
| Syslog | Yes |
| DHCP client | Yes |
| Input bandwidth | 80 Mbit/s |
| Output bandwidth | 60 Mbit/s |
| Wi-Fi | No |
| Number of HDDs supported | 1 |
| Maximum storage capacity | 10 TB |
| HDD interface | SATA |
| Ethernet LAN (RJ-45) ports | 5 |
| Power over Ethernet (PoE) | Yes |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Power over Ethernet (PoE) ports quantity | 4 |
| Ethernet WAN | Yes |
| HDMI output | Yes |
| HDMI ports quantity | 1 |
| VGA (D-Sub) output ports | 1 |
| USB 2.0 ports quantity | 2 |
| Line-in | Yes |
| Audio output | 1 |
| Networking standards | IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u |
| Supported network protocols | TCP/IP, DHCP, DNS, NTP, UPnP |
| Rack mounting | No |
| LED indicators | Yes |
| Product colour | White |
| Built-in display | No |
| Power consumption (typical) | 4.82 W |
| Output current | 1.31 A |
| Output voltage | 53.5 V |
| Total Power over Ethernet (PoE) budget | 53 W |
| Redundant power supply (RPS) support | Yes |
| Operating temperature (T-T) | -10 - 55 °C |
| Sustainability compliance | Yes |
| Compliance certificates | CE, EAC, Federal Communications Commission (FCC) |
| Width | 200.3 mm |
| Depth | 200.3 mm |
| Height | 43 mm |
| Package width | 251.5 mm |
| Package depth | 401.5 mm |
| Package height | 64.5 mm |
| Package weight | 1.37 kg |
| AC adapter included | Yes |
| Quick installation guide | Yes |
