TP-Link Archer C24 AC750 Dual-Band Wi-Fi Router 2.4GHz 300Mbps 5GHz 433Mbps 4xLAN 1xWAN 4xAntennas, WPS, Router Access Point and Range Extender Modes

TP-Link Archer C24 AC750 Dual-Band Wi-Fi Router • High-Speed Wi-Fi—AC750 dual-band is ideal for HD video streaming, high-speed downloading. • Far-Reaching Coverage—4× antennas deliver far-reaching Wi-Fi and reliable connections. • Multi-Mode 3 in 1—Supports Router, Access Point, and Range Extender to add flexibilities. • Parental Controls—Manages when and how connected devices can access the internet. • Guest Network—Provides separate access for guests while securing the host network. • Smooth HD Streaming—Supports IGMP Proxy/Snooping, Bridge and Tag VLAN to optimize IPTV streaming. • IPv6 Supported—Compatible with the IPv6 (the latest Internet Protocol version 6). • Compact and Mountable—Designed to conserve space and complement any décor. WIRELESS Standards Wi-Fi 5 IEEE 802.11ac/n/a 5 GHz IEEE 802.11n/b/g 2.4 GHz WiFi Speeds AC750 5 GHz: 433 Mbps (802.11ac) 2.4 GHz: 300 Mbps (802.11n) WiFi Range 2 Bedroom Houses 4× Fixed Antennas Multiple antennas form a signal-boosting array to cover more directions and large areas WiFi Capacity Medium Dual-Band Allocate devices to different bands for optimal performance Working Modes Router Mode Access Point Mode Range Extender Mode HARDWARE Processor Single-Core CPU Ethernet Ports 1× 10/100 Mbps WAN Port 4× 10/100 Mbps LAN Ports Buttons WPS Button Reset Button Power 5 V ⎓ 0.6 A SECURITY WiFi Encryption WEP WPA WPA2 WPA/WPA2-Enterprise (802.1x) Network Security SPI Firewall Access Control IP & MAC Binding Application Layer Gateway Guest Network 1× 5 GHz Guest Network 1× 2.4 GHz Guest Network PHYSICAL Dimensions (W×D×H) (115 x 106.7 x 24.3 mm) WiFi Reception Sensitivity 5GHz: 11a 54M: -76dBm; 11ac VHT20 MCS8: -71dBm; 11ac VHT40 MCS9: -66dBm; 11ac VHT80 MCS9: -62dBm 2.4GHz: 11g 54M: -76dBm11n; HT20 MCS7: -73dBm; 11n HT40 MCS7: -71dBm
