Processor Manufacturer
|
Intel |
|
Processor family
|
Intel® Core™ i7 |
|
Processor generation
|
Intel® Core™ i7 (14th gen) |
|
Processor Model
|
i7-14700 |
|
Processor Cores
|
20 |
|
Processor threads
|
28 |
|
Processor boost frequency
|
5.4 GHz |
|
Performance cores
|
8 |
|
Efficient cores
|
12 |
|
Performance-core Max Turbo Frequency
|
5.3 GHz |
|
Efficient-core Max Turbo Frequency
|
4.2 GHz |
|
Performance-core base frequency
|
2.1 GHz |
|
Efficient-core base frequency
|
1.5 GHz |
|
Processor cache
|
33 MB |
|
Processor cache type
|
Smart Cache |
|
Processor base power
|
65 W |
|
Maximum turbo power
|
219 W |
|
Internal memory
|
16 GB |
|
Maximum internal memory
|
64 GB |
|
Internal memory type
|
DDR5-SDRAM |
|
Memory layout (slots x size)
|
2 x 8 GB |
|
Memory slots
|
2x DIMM |
|
Memory clock speed
|
5600 MHz |
|
Memory channels
|
Dual-channel |
|
Total Storage Capacity
|
512 GB |
|
Storage media
|
SSD |
|
Optical Drive Type
|
No |
|
Number of storage drives installed
|
1 |
|
Total SSDs capacity
|
512 GB |
|
Number of SSDs installed
|
1 |
|
SSD capacity
|
512 GB |
|
SSD interface
|
PCI Express 4.0 |
|
NVMe
|
Yes |
|
SSD Form Factor
|
M.2 |
|
Card reader integrated
|
No |
|
Discrete graphics card
|
No |
|
On-board graphics card
|
Yes |
|
Discrete graphics card model
|
Not available |
|
On-board GPU manufacturer
|
Intel |
|
On-board graphics card family
|
Intel® UHD Graphics |
|
On-board graphics card model
|
Intel UHD Graphics 770 |
|
Ethernet LAN
|
Yes |
|
Ethernet LAN data rates
|
100,1000 Mbit/s |
|
Cabling technology
|
10/100/1000Base-T(X) |
|
Wi-Fi
|
Yes |
|
Top Wi-Fi standard
|
Wi-Fi 6 (802.11ax) |
|
Wi-Fi standards
|
Wi-Fi 6 (802.11ax) |
|
WLAN controller manufacturer
|
Intel |
|
WLAN controller model
|
Intel Wi-Fi 6 AX201 |
|
Bluetooth
|
Yes |
|
Bluetooth Version
|
5.2 |
|
USB 2.0 ports quantity
|
4 |
|
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
|
4 |
|
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
|
1 |
|
HDMI ports quantity
|
1 |
|
HDMI version
|
2.1 |
|
DisplayPorts quantity
|
1 |
|
DisplayPort version
|
1.4a |
|
Ethernet LAN (RJ-45) ports
|
1 |
|
Microphone in
|
Yes |
|
Combo headphone/mic port
|
Yes |
|
Chassis type
|
SFF |
|
Colour name
|
Black |
|
Volume
|
8.2 L |
|
Cable lock slot
|
Yes |
|
Cable lock slot type
|
Kensington |
|
Product colour
|
Black |
|
Motherboard chipset
|
Intel Q670 |
|
Audio chip
|
Realtek ALC623-CG |
|
Audio system
|
High Definition Audio |
|
Built-in speaker(s)
|
Yes |
|
Number of speakers
|
1 |
|
Password protection
|
Yes |
|
Password protection type
|
BIOS, HDD, Power on, Supervisor |
|
Trusted Platform Module (TPM)
|
Yes |
|
Product Type
|
PC |
|
Operating system installed
|
Windows 11 Pro |
|
Operating System Architecture
|
64-bit |
|
Operating system language
|
English |
|
Power Supply
|
260 W |
|
Power supply input voltage
|
100 - 240 V |
|
Power supply input frequency
|
50/60 Hz |
|
Operating temperature (T-T)
|
5 - 35 °C |
|
Storage temperature (T-T)
|
-40 - 60 °C |
|
Operating relative humidity (H-H)
|
20 - 80% |
|
Storage relative humidity (H-H)
|
10 - 90% |
|
Operating altitude
|
0 - 3048 m |
|
Non-operating altitude
|
0 - 12192 m |
|
Compliance certificates
|
RoHS |
|
Certification
|
ErP Lot 3
GREENGUARD
RoHS compliant
TCO Certified 9.0
MIL-STD-810H military test passed |
|
Sustainability compliance
|
Yes |
|
Sustainability certificates
|
ErP, TCO |
|
Width
|
92.5 mm |
|
Depth
|
297.7 mm |
|
Height
|
339.5 mm |
|
Weight
|
5.3 kg |
|
Package width
|
195 mm |
|
Package depth
|
395 mm |
|
Package height
|
530 mm |
|
Package Weight
|
7.6 kg |
|
Mouse included
|
Yes |
|
Mouse connectivity
|
Wired |
|
Keyboard included
|
Yes |
|
Keyboard connectivity
|
Wired |
|
Display included
|
No |
