Switch type
|
Managed |
|
Switch layer
|
L2 |
|
Quality of Service (QoS) support
|
Yes |
|
Web-based management
|
Yes |
|
Traffic classification
|
Yes |
|
ARP inspection
|
Yes |
|
Configuring Location Settings (CLI)
|
Yes |
|
System event log
|
Yes |
|
Basic switching RJ-45 Ethernet ports quantity
|
24 |
|
Basic switching RJ-45 Ethernet ports type
|
Gigabit Ethernet (10/100/1000) |
|
SFP module slots quantity
|
2 |
|
Console port
|
RJ-45 |
|
Power Connector
|
AC-in jack |
|
Networking standards
|
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1af, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
|
10G support
|
No |
|
Cable types supported
|
Cat5e |
|
Port mirroring
|
Yes |
|
Flow control support
|
Yes |
|
Link aggregation
|
Yes |
|
Rate limiting
|
Yes |
|
Spanning tree protocol
|
Yes |
|
Ethernet LAN data rates
|
10,100,1000 Mbit/s |
|
Auto-negotiation
|
Yes |
|
Active link detection
|
Yes |
|
MAC address auto-learning supported
|
Yes |
|
MAC address auto-aging supported
|
Yes |
|
VLAN support
|
Yes |
|
Number of VLANs
|
4000 |
|
Switching capacity
|
52 Gbit/s |
|
Forwarding rate
|
38.7 Mpps |
|
MAC address table
|
8000 entries |
|
Number of queues
|
8 |
|
Jumbo frames support
|
Yes |
|
Jumbo frames
|
10000 |
|
DHCP features
|
DHCP snooping |
|
IGMP snooping
|
Yes |
|
Security algorithms
|
HTTPS, SSH |
|
SSH/SSL support
|
Yes |
|
Loop protection
|
Yes |
|
BPDU filtering/protection
|
Yes |
|
IP-MAC-Port binding
|
Yes |
|
Authentication
|
Port-based authentication |
|
Password protection
|
Yes |
|
Authentication type
|
IEEE 802.1x |
|
Queue scheduling algorithms
|
SP, WFQ, Weighted Round Robin (WRR) |
|
MAC address entries
|
Dynamic MAC address entries, Static MAC address entries |
|
Multicast support
|
Yes |
|
Multicast features
|
Interface-based multicast traffic statistics |
|
Supported network protocols
|
IPv4, IPv6 |
|
Rack mounting
|
Yes |
|
Product colour
|
Grey |
|
LED indicators
|
PoE, Power, System |
|
Number of fans
|
3 fan(s) |
|
Noise Level
|
45 dB |
|
Power Source
|
AC |
|
Power supply included
|
Yes |
|
Number of power supply units
|
1 |
|
AC input voltage
|
100 - 240 V |
|
AC input frequency
|
50 - 60 Hz |
|
Power Consumption (Typical)
|
18 W |
|
Power consumption (max)
|
400 W |
|
Power Over Ethernet (PoE)
|
Yes |
|
Power over Ethernet plus (PoE+) ports quantity
|
8 |
|
Power over Ethernet (PoE) power per port
|
30 W |
|
Total Power over Ethernet (PoE) budget
|
380 W |
|
Operating temperature (T-T)
|
0 - 40 °C |
|
Storage temperature (T-T)
|
-20 - 70 °C |
|
Operating relative humidity (H-H)
|
10 - 90% |
|
Storage relative humidity (H-H)
|
10 - 95% |
|
Width
|
440 mm |
|
Depth
|
293 mm |
|
Height
|
44 mm |
|
Weight
|
5 kg |
|
