Switch type
|
Managed |
|
Switch layer
|
L3 |
|
Quality of Service (QoS) support
|
Yes |
|
Web-based management
|
Yes |
|
Cloud-managed
|
No |
|
Configuring Location Settings (CLI)
|
Yes |
|
System event log
|
Yes |
|
MIB support
|
RFC2893, RFC4213, RFC4291, RFC2464, RFC2462, RFC4862, RFC2461, RFC4861, RFC2573, RFC1321, RFC2284, RFC2865, RFC2716, RFC3580, RFC826, RFC2463, RFC4443, RFC792, RFC793, RFC768, RFC791, RFC2389, RFC4113, RFC4022, RFC2618, RFC2674, RFC1398, RFC1643, RFC1650, RFC2358, RFC2665, RFC2021, RFC271, RFC1757, RFC2819, RFC1442, RFC1901, RFC1902, RFC1903, RFC1904, RFC1905, RFC1906, RFC1907, RFC1908, RFC2578, RFC3418, RFC2573, RFC2575, RFC2576, RFC1212, RFC1213, RFC1215, RFC1493, RFC1157, RFC2620, |
|
Basic switching RJ-45 Ethernet ports quantity
|
48 |
|
Basic switching RJ-45 Ethernet ports type
|
No |
|
SFP+ module slots quantity
|
4 |
|
Console port
|
RJ-45 |
|
Networking standards
|
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
|
10G support
|
Yes |
|
Flow control support
|
Yes |
|
Link aggregation
|
Yes |
|
Broadcast storm control
|
Yes |
|
Auto MDI/MDI-X
|
Yes |
|
Spanning tree protocol
|
Yes |
|
Head-of-line (HOL) blocking
|
Yes |
|
VLAN support
|
Yes |
|
Virtual LAN features
|
Voice VLAN |
|
Number of VLANs
|
4094 |
|
Switching capacity
|
176 Gbit/s |
|
Forwarding rate
|
130.95 Mpps |
|
MAC address table
|
32000 entries |
|
Static route
|
Yes |
|
Number of static routes
|
124 |
|
Jumbo frames support
|
Yes |
|
Jumbo frames
|
12000 |
|
Packet buffer memory
|
16 MB |
|
DHCP features
|
DHCP client, DHCP server, DHCP snooping |
|
Access Control List (ACL)
|
Yes |
|
Access Control List (ACL) rules
|
768 |
|
IGMP snooping
|
Yes |
|
Security algorithms
|
EAP, LEAP, PEAP, SSH, TTLS |
|
Loop protection
|
Yes |
|
IP-MAC-Port binding
|
Yes |
|
Queue scheduling algorithms
|
Weighted Round Robin (WRR) |
|
Multicast support
|
Yes |
|
Rack mounting
|
Yes |
|
Product colour
|
Black |
|
LED indicators
|
Activity, Link, Power, Speed |
|
Electromagnetic compatibility
|
CE A, VCCI A, FCC A, IC, BSMI |
|
Memory Type
|
DDR3-SDRAM |
|
Internal memory
|
2048 MB |
|
Flash Memory
|
64 MB |
|
Noise Level
|
51.2 dB |
|
Mean time between failures (MTBF)
|
309053.1 h |
|
Power supply included
|
Yes |
|
AC input voltage
|
100 - 240 V |
|
AC input frequency
|
50 - 60 Hz |
|
Power consumption (max)
|
467.3 W |
|
Power Over Ethernet (PoE)
|
Yes |
|
Power over Ethernet (PoE) ports quantity
|
48 |
|
Power over Ethernet (PoE) power per port
|
15.4 W |
|
Total Power over Ethernet (PoE) budget
|
370 W |
|
Operating temperature (T-T)
|
-5 - 50 °C |
|
Storage temperature (T-T)
|
-20 - 70 °C |
|
Operating relative humidity (H-H)
|
0 - 95% |
|
Storage relative humidity (H-H)
|
0 - 95% |
|
Heat dissipation
|
1512.676 BTU/h |
|
Width
|
440 mm |
|
Depth
|
430 mm |
|
Height
|
44 mm |
|
Weight
|
3.85 kg |
|
Package width
|
393 mm |
|
Package depth
|
563 mm |
|
Package height
|
89 mm |
|
Package Weight
|
5.17 kg |
|
Shipping (inner) case height
|
42.8 cm |
|
Shipping (inner) case width
|
47.8 cm |
|
Shipping (inner) case length
|
58.5 cm |
|
Shipping (inner) case net weight
|
22.9 kg |
|
Products per shipping (inner) case
|
5 pc(s) |
|
Pallet gross weight (air)
|
456.1 kg |
|
Master (outer) cases per pallet (air)
|
16 pc(s) |
|
Products per pallet (air)
|
80 pc(s) |
|
Pallet gross length
|
110 cm |
|
Pallet gross width
|
120 cm |
|
Pallet height (air)
|
184.7 cm |
|
Pallet gross weight (sea)
|
456.1 kg |
|
Master (outer) cases per pallet (sea)
|
16 pc(s) |
|
Products per pallet (sea)
|
80 pc(s) |
|
Pallet height (sea)
|
184.7 cm |
|
Shipping (inner) case gross weight
|
27.4 kg |
|
Certification
|
CB, UL, BSMI, CCC |
|
Harmonized System (HS) code
|
85176990 |
|
