SFP transceiver type
|
Fiber optic |
|
Maximum data transfer rate
|
1000 Mbit/s |
|
Interface Type
|
SFP |
|
Single-mode fiber (SMF) supported
|
No |
|
Multi-mode fiber (MMF) supported
|
Yes |
|
Fiber optic connector
|
LC |
|
SFP transceiver standard
|
SX |
|
Maximum transfer distance
|
550 m |
|
Wavelength
|
850 nm |
|
Networking standards
|
IEEE 802.3x |
|
Duplex system
|
Full |
|
Product colour
|
Metallic |
|
Housing Material
|
Metal |
|
Hot-Plug support
|
Yes |
|
Maximum voltage
|
6 V |
|
Certification
|
MSA, RoHS |
|
Operating temperature (T-T)
|
0 - 40 °C |
|
Storage temperature (T-T)
|
-40 - 85 °C |
|
Width
|
13.8 mm |
|
Depth
|
57.2 mm |
|
Height
|
8.5 mm |
|
Package width
|
74 mm |
|
Package depth
|
131 mm |
|
Package height
|
49 mm |
|
Package Weight
|
64 g |
|
Shipping (inner) case length
|
36 cm |
|
Shipping (inner) case width
|
26 cm |
|
Shipping (inner) case height
|
31 cm |
|
Shipping (inner) case net weight
|
3.2 kg |
|
Products per shipping (inner) case
|
50 pc(s) |
|
Pallet gross weight (air)
|
246.8 kg |
|
Master (outer) cases per pallet (air)
|
54 pc(s) |
|
Products per pallet (air)
|
2700 pc(s) |
|
Pallet gross length
|
102 cm |
|
Pallet gross width
|
122 cm |
|
Pallet height (air)
|
199 cm |
|
Pallet gross weight (sea)
|
246.8 kg |
|
Master (outer) cases per pallet (sea)
|
54 pc(s) |
|
Products per pallet (sea)
|
2700 pc(s) |
|
Pallet height (sea)
|
199 cm |
|
Shipping (inner) case gross weight
|
4.2 kg |
|
Harmonized System (HS) code
|
85369010 |
|
Manufacturer
|
|
