Switch type
|
Managed |
|
Switch layer
|
L2 |
|
Quality of Service (QoS) support
|
Yes |
|
Web-based management
|
Yes |
|
Traffic classification
|
Yes |
|
System event log
|
Yes |
|
MIB support
|
RFC1213MIB II, RFC1493, RFC1907, RFC1757, 2819, RFC2021, RFC1398, 1643, 1650, 2358, 2665, RFC2674, 4363, RFC 2233, 2863, RFC 2618, RFC 2620, RFC 2925 |
|
Basic switching RJ-45 Ethernet ports quantity
|
24 |
|
Basic switching RJ-45 Ethernet ports type
|
Gigabit Ethernet (10/100/1000) |
|
SFP module slots quantity
|
4 |
|
Fiber optic connector
|
SFP |
|
Console port
|
RJ-45 |
|
Networking standards
|
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
|
10G support
|
No |
|
Copper ethernet cabling technology
|
10BASE-T, 100BASE-TX, 100BASE-T, 1000BASE-T |
|
Port mirroring
|
Yes |
|
Full duplex
|
Yes |
|
IP routing
|
Yes |
|
Flow control support
|
Yes |
|
Link aggregation
|
Yes |
|
Rate limiting
|
Yes |
|
Auto MDI/MDI-X
|
Yes |
|
Spanning tree protocol
|
Yes |
|
Auto-negotiation
|
Yes |
|
VLAN support
|
Yes |
|
Virtual LAN features
|
Voice VLAN, Tagged VLAN, MAC address-based VLAN, Port-based VLAN |
|
Number of VLANs
|
4094 |
|
Fiber ethernet cabling technology
|
1000BASE-X |
|
Switching capacity
|
56 Gbit/s |
|
Forwarding rate
|
41.7 Mpps |
|
MAC address table
|
16000 entries |
|
Store-and-forward
|
Yes |
|
Number of queues
|
8 |
|
Number of static routes
|
32 |
|
Jumbo frames support
|
Yes |
|
Jumbo frames
|
9216 |
|
Packet buffer memory
|
1.5 MB |
|
DHCP features
|
DHCP client |
|
Access Control List (ACL)
|
Yes |
|
Access Control List (ACL) rules
|
256 |
|
IGMP snooping
|
Yes |
|
Security algorithms
|
802.1x RADIUS, SNMP, SSH |
|
SSH/SSL support
|
Yes |
|
Loop protection
|
Yes |
|
BPDU filtering/protection
|
Yes |
|
IP-MAC-Port binding
|
Yes |
|
Authentication
|
Guest VLAN, MAC-based authentication, Port-based authentication |
|
Multicast support
|
Yes |
|
Multicast Listener Discovery (MLD) snooping
|
MLD v1, MLD v2 |
|
Rack mounting
|
Yes |
|
Form factor
|
1U |
|
Product colour
|
Black, Grey |
|
LED indicators
|
Activity, Fan fail, Link, Power, Speed |
|
Number of fans
|
2 fan(s) |
|
Safety
|
CCC, CE LVD, UL/cUL |
|
Electromagnetic compatibility
|
FCC A, CE A, VCCI, C-Tick, BSMI, CCC |
|
Built-in processor
|
Yes |
|
Memory Type
|
DDR3-SDRAM |
|
Internal memory
|
128 MB |
|
Flash Memory
|
32 MB |
|
Noise Level
|
52.4 dB |
|
Mean time between failures (MTBF)
|
294101 h |
|
AC input voltage
|
100 - 240 V |
|
AC input frequency
|
50 - 60 Hz |
|
Power Consumption (Typical)
|
27.49 W |
|
Power Over Ethernet (PoE)
|
Yes |
|
Power over Ethernet (PoE) ports quantity
|
24 |
|
Operating temperature (T-T)
|
-5 - 50 °C |
|
Storage temperature (T-T)
|
-40 - 70 °C |
|
Operating relative humidity (H-H)
|
10 - 90% |
|
Storage relative humidity (H-H)
|
5 - 90% |
|
Heat dissipation
|
850.58 BTU/h |
|
Width
|
440 mm |
|
Depth
|
210 mm |
|
Height
|
44 mm |
|
Package width
|
365 mm |
|
Package depth
|
521 mm |
|
Package height
|
92 mm |
|
Package Weight
|
5.18 kg |
|
Shipping (inner) case height
|
39.3 cm |
|
Shipping (inner) case width
|
29.5 cm |
|
Shipping (inner) case length
|
53.9 cm |
|
Shipping (inner) case net weight
|
15.6 kg |
|
Products per shipping (inner) case
|
3 pc(s) |
|
Pallet gross weight (air)
|
419.7 kg |
|
Master (outer) cases per pallet (air)
|
24 pc(s) |
|
Products per pallet (air)
|
72 pc(s) |
|
Pallet gross length
|
110 cm |
|
Pallet gross width
|
120 cm |
|
Pallet height (air)
|
131.4 cm |
|
Pallet gross weight (sea)
|
682.9 kg |
|
Master (outer) cases per pallet (sea)
|
40 pc(s) |
|
Products per pallet (sea)
|
120 pc(s) |
|
Pallet height (sea)
|
2.1 m |
|
Shipping (inner) case gross weight
|
16.4 kg |
|
Certification
|
IEC61000-4-5, RoHS |
|
Harmonized System (HS) code
|
85176990 |
|
