Switch type
|
Unmanaged |
|
Quality of Service (QoS) support
|
Yes |
|
Basic switching RJ-45 Ethernet ports quantity
|
24 |
|
Basic switching RJ-45 Ethernet ports type
|
Gigabit Ethernet (10/100/1000) |
|
Power Connector
|
AC-in jack |
|
Networking standards
|
IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x |
|
10G support
|
No |
|
Copper ethernet cabling technology
|
10BASE-T, 100BASE-T, 1000BASE-T |
|
Cable types supported
|
Cat3, Cat4, Cat5, Cat5e |
|
Full duplex
|
Yes |
|
Flow control support
|
Yes |
|
Broadcast storm control
|
Yes |
|
Auto MDI/MDI-X
|
Yes |
|
Active link detection
|
Yes |
|
MAC address auto-learning supported
|
Yes |
|
MAC address auto-aging supported
|
Yes |
|
Switching capacity
|
48 Gbit/s |
|
Forwarding rate
|
35.71 Mpps |
|
MAC address table
|
8000 entries |
|
Store-and-forward
|
Yes |
|
Number of queues
|
8 |
|
Jumbo frames support
|
Yes |
|
Jumbo frames
|
10000 |
|
Packet forwarding rate (1 Gbps)
|
14880 pps |
|
Packet forwarding rate (100 Mbps)
|
148800 pps |
|
Packet forwarding rate (10 Mbps)
|
1488000 pps |
|
Packet buffer memory
|
0.5 MB |
|
Rack mounting
|
Yes |
|
Stackable
|
Yes |
|
Form factor
|
1U |
|
Product colour
|
Black, Silver |
|
Housing Material
|
Metal |
|
LED indicators
|
Activity, Link, Power, Speed |
|
Electromagnetic compatibility
|
ICES-003 Class A, FCC Class A, RCM Class A, BSMI Class A, CE Class A, VCCI A, CCC, KCC |
|
Noise Level
|
0 dB |
|
Mean time between failures (MTBF)
|
863100 h |
|
Power supply included
|
Yes |
|
AC input voltage
|
100 - 240 V |
|
AC input frequency
|
50 - 60 Hz |
|
Input current
|
0.3 A |
|
Power consumption (max)
|
13.3 W |
|
Power Over Ethernet (PoE)
|
No |
|
Operating temperature (T-T)
|
0 - 40 °C |
|
Storage temperature (T-T)
|
-10 - 70 °C |
|
Operating relative humidity (H-H)
|
0 - 95% |
|
Storage relative humidity (H-H)
|
0 - 95% |
|
Heat dissipation
|
45.35 BTU/h |
|
Width
|
280 mm |
|
Depth
|
180 mm |
|
Height
|
44 mm |
|
Weight
|
1.3 kg |
|
Certification
|
cUL/UL
CE LVD
CCC
CB
BSMI |
|
