Switch type
|
Managed |
|
Switch layer
|
L2 |
|
Quality of Service (QoS) support
|
Yes |
|
Web-based management
|
Yes |
|
System event log
|
Yes |
|
Basic switching RJ-45 Ethernet ports quantity
|
16 |
|
Basic switching RJ-45 Ethernet ports type
|
Gigabit Ethernet (10/100/1000) |
|
Networking standards
|
IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
|
10G support
|
No |
|
Copper ethernet cabling technology
|
10BASE-T, 10BASE-TX, 1000BASE-T |
|
Port mirroring
|
Yes |
|
Full duplex
|
Yes |
|
Flow control support
|
Yes |
|
Link aggregation
|
Yes |
|
Broadcast storm control
|
Yes |
|
Rate limiting
|
Yes |
|
Auto MDI/MDI-X
|
Yes |
|
Spanning tree protocol
|
Yes |
|
Head-of-line (HOL) blocking
|
Yes |
|
Ethernet LAN data rates
|
10,100,1000 Mbit/s |
|
Auto-negotiation
|
Yes |
|
VLAN support
|
Yes |
|
Virtual LAN features
|
Port-based VLAN, Voice VLAN |
|
Number of VLANs
|
128 |
|
Switching capacity
|
32 Gbit/s |
|
Forwarding rate
|
23.81 Mpps |
|
MAC address table
|
8000 entries |
|
Store-and-forward
|
Yes |
|
Number of queues
|
4 |
|
Jumbo frames support
|
Yes |
|
Jumbo frames
|
9216 |
|
Packet buffer memory
|
4.1 MB |
|
DHCP features
|
DHCP client |
|
IGMP snooping
|
Yes |
|
Security algorithms
|
SNMP, SSL/TLS |
|
Queue scheduling algorithms
|
SPQ, Weighted Round Robin (WRR) |
|
Multicast support
|
Yes |
|
Rack mounting
|
Yes |
|
Product colour
|
Black |
|
LED indicators
|
Yes |
|
Built-in processor
|
Yes |
|
Processor frequency
|
125 MHz |
|
Memory Type
|
DRAM |
|
Flash Memory
|
16 MB |
|
Noise Level
|
0 dB |
|
Fanless
|
Yes |
|
Mean time between failures (MTBF)
|
710519 h |
|
AC input voltage
|
100 - 240 V |
|
Power consumption (max)
|
10.1 W |
|
Power Over Ethernet (PoE)
|
No |
|
Operating temperature (T-T)
|
-5 - 50 °C |
|
Storage temperature (T-T)
|
-40 - 70 °C |
|
Operating relative humidity (H-H)
|
0 - 95% |
|
Storage relative humidity (H-H)
|
0 - 95% |
|
Operating altitude
|
0 - 2000 m |
|
Heat dissipation
|
34.46 BTU/h |
|
Width
|
280 mm |
|
Depth
|
180 mm |
|
Height
|
44 mm |
|
Weight
|
1.27 kg |
|
Certification
|
EMI FCC A, CE A, VCCI A, C-Tick, BSMI, CCC
cUL, CE LVD, CB, BSMI, CCC |
|
Harmonized System (HS) code
|
85176990 |
